Buried Lamp

Currency

Print Export

AED

MD-B01 Series

MD-B01012MD-B01018MD-B0103MD-B0106MD-B0109
Voltage: AC220-240V 50/60Hz
Power: 12W
Body Size:Ф120x90mm
Hole Size: Ф60mm
Luminous: 960Lm
CRI: ≥70
Beam Angle: 30°
Material: Aluminum+Glass+ABC
LED Type: COB
PF: >0.5
Surge: 1.5KV
Voltage: AC220-240V 50/60Hz
Power: 18W
Body Size:Ф150x90mm
Hole Size: Ф60mm
Luminous: 1500Lm
CRI: ≥70
Beam Angle: 30°
Material: Aluminum+Glass+ABC
LED Type: COB
PF: >0.5
Surge: 1.5KV
Voltage: AC220-240V 50/60Hz
Power: 3W
Body Size:Ф65x80mm
Hole Size: Ф60mm
Luminous: 240Lm
CRI: ≥70
Beam Angle: 30°
Material: Aluminum+Glass+ABC
LED Type: COB
PF: >0.5
Surge: 1.5KV
Voltage: AC220-240V 50/60Hz
Power: 6W
Body Size:Ф80x90mm
Hole Size: Ф60mm
Luminous: 520Lm
CRI: ≥70
Beam Angle: 30°
Material: Aluminum+Glass+ABC
LED Type: COB
PF: >0.5
Surge: 1.5KV
Voltage: AC220-240V 50/60Hz
Power: 9W
Body Size:Ф100x90mm
Hole Size: Ф60mm
Luminous: 810Lm
CRI: ≥70
Beam Angle: 30°
Material: Aluminum+Glass+ABC
LED Type: COB
PF: >0.5
Surge: 1.5KV
QuotationPrint
型号参数报价表
Model NOParameterQuotation

Product Advantages

Promotion Introduction
